What is the MWF-4 Semi-Automatic Jujube Puree Single Head Filling Machine?

This MWF-4 Semi-Automatic Jujube Puree Single Head Filling Machine is a paste/sauce filler that combines advanced filling technology with functional design. It has a modern horizontal flat structure that is compact and practical. The material cylinder may create a vacuum chamber and is sucked at negative pressure. This machine uses pneumatic parts (cylinders) and a piston-type push-rod construction—filling materials with high viscosity and low fluidity.

This jujube puree filling equipment uses a piston-type push rod structure. A strong pushing force from the cylinder moves the piston head. The valve opens, and the outlet valve shuts when the main cylinder returns to the live plug head. The material will be sucked into the material cylinder because of the difference in pressure there. The focus of the work is on this. The main cylinder will push the piston head outward after the completion of the suction stroke. The valve on the inflow port is now closed, while the valve on the discharge port is currently open. The substance is forced out of the cylinder by the piston’s mouth. The container is filled during the filling stroke through the discharge port.

What are the technical parameters of the MWF-4 Semi-Automatic Jujube Puree Single Head Filling Machine?

Model: Horizontal MWF-4 semi-automatic paste and sauce filling machine

Operation Mode: Air compressor with 220V voltage use

Power Supply: 220V50Hz

Filling Specification: 50-1000 grams (customizable)

Filling Accuracy: ≤± 0.5%

Filling Speed: 1 to 25 bottles per minute

Material Barrel Volume: 20-40kg

Matching Air Pressure: 0.4-0.9MPa

Gas Consumption: ≥0.1m3 per minute (provide air compressor)

What are the features of the MWF-4 Semi-Automatic Jujube Puree Single Head Filling Machine?

· Stainless steel outlet: long-lasting, high-precision anti-drip filling mechanism.

· High-Quality PTFE Piston: Tetrafluoroethylene material, excellent sealing, high-temperature resistance, durable.

· High-Quality Cylinder: high power, consistent air pressure, robust, corrosion-resistant accessories.

· Three-way rotary valve: beautiful, stainless steel, easy to disassemble and clean. Consistent excellent filling experience.

· Filling volume rocker. Demand determines scale: easy adjustment and use.

· Engine Start/Stop: Intelligent operation, simple to start, stable and long-lasting

· Customizable: Handle various nozzle sizes: 4mm, 6mm, 8mm, 10mm, 12mm, etc. Special customized nozzle sizes are also accepted.

What are the characteristics of the MWF-4 Semi-Automatic Jujube Puree Single Head Filling Machine?

1. Compressed air for power, no impact, and harsh friction make it safe for use in anti-riot situations.

2. Fixed volume metering and piston-type push rod construction provide excellent filling accuracy and low error of less than 1%.

3. The filling control handle allows for speed and accuracy adjustments.

4. Features automated absorption, quantitative filling, uniform discharge, emergency shutdown, and variable filling capacity and speed change.

5. The filling head has a cylinder valve or mechanical valve and an anti-dripping plugging head to prevent the drawing head from dropping.

6. Clamps allow easy assembly, disassembly, cleaning, and maintenance.

7. Material-contact components are 316L or 304 stainless steel. GMP-compliant.

8. Manual/automatic machine set. Continuous machine filling and manual pedal control.

What is the filling process of the MWF-4 Semi-Automatic Jujube Puree Single Head Filling Machine?

This MWF-4 Semi-Automatic Jujube Puree Single Head Filling Machine is a compact and adaptable tabletop machine. It is a device that fills containers, jars, or tubes with paste, semi-solid, or liquid material. Filling the semi-automatic filling machine with the selected product material starts the operation. The container/bottle may then be manually placed in the filling dispenser. A single person can simply handle the equipment. It is constructed from high-grade stainless steel and features a straightforward operating mechanism. This filler is comprised of high-quality components that, when combined, allow it to operate smoothly and efficiently.

MWF-4 Semi-Automatic Jujube Puree Single Head Filling Machine Parts

How to operate the MWF-4 Semi-Automatic Jujube Puree Single Head Filling Machine?

This MWF-4 Semi-Automatic Jujube Puree Single Head Filling Machine delivers specified volume into containers reliably and consistently. This machine is excellent for filling medium to high-viscosity liquid products that range from paste to semi-solid and include particles such as jujubee puree. It uses a single-piston pump to measure and fill products into containers.

This machine has a large hopper for filling your products. Simply open the connecting clamp to attach the hopper. Close the connecting clamp after correctly positioning the hopper on top.

The filling nozzle is then attached to the machine. To do this, you need to unhook the connecting clamp. Put the filling nozzle on the outlet in the right place. Then, make sure the filling nozzle is tight by closing the connection clamp. For this machine to work, it needs an exhaust to fill in and discharge the product. So, the next step is to connect the exhaust pipe to the machine. After that, plug the main power cord into the machine and turn on the green button.

To operate the machine automatically, toggle the switch to the auto position. Go to job mode if you want to use it with a pedal.

Now, pour the jujubee puree or other product material into the hopper. Then set the flow of liquid. Put a container that is empty beneath the nozzle. To increase the flow of the process, turn the first throttle valve counterclockwise. If it’s going too fast, you can slow it down by turning the same valve in the opposite direction. After setting the flow rate, set how much liquid you want to feel in your bottle. To do that, turn the hand wheel to set the flow. You may have to try a few times until you get the right amount. Now, try to use the pedal to fill a few bottles by hand. Put the bottle under the filling nozzle and press the pedal to let the liquid out. Fill in until all the bottles are full.

This machine can also operate in automatic mode. To do so, determine first the rate time. After each discharge, the piston’s backward movement floor allows the operator to replace the container. Turn the second throttle valve anticlockwise to shorten the weight time. If it is too fast, adjust the throttle valve clockwise to increase the weight time. It’s best to increase the weight time to have enough time to change the container. Then determine the quantity of liquid you wish to put within the bottle after the weight time is set. Now, begin automatically pouring the liquid into bottles.

This MWF-4 Semi-Automatic Jujube Puree Single Head Filling Machine’s main function is to dispense a precise dosage of your product. It is excellent for filling a wide range of liquid products from various industries.

What are the other applications of this MWF-4 Semi-Automatic Jujube Puree Single Head Filling Machine?

This MWF-4 Semi-Automatic Jujube Puree Single Head Filling Machine is a sauce/paste filling machine that can also fill other liquids and pastes. Water, juice, oil, sauce, toothpaste, cosmetic paste, hand cream, honey, peanut butter, and so on. It is used widely in food, cosmetics, medicine, chemical, and other industries.

How MWF-4 is Semi-Automatic Jujube Puree Single Head Filling Machine prepared before shipping?

1. We give the machine an anti-rust treatment before shipping.

2. We use plastic wrap or an aluminum foil bag to protect the machine before shipping.

3. For packaging, we use durable plywood hardwood boxes. Solid wooden box packing can ensure the machine’s protection throughout transportation.
