Multilane Packing Machine

Multilane packing machines are best for packaging milk powder, beverages,
pharmaceuticals, health goods, sauces, powders, liquids, granules, non-food,
and other batch-produced products. Fabricate product seal forms to suit
a wide range of production needs.

Makwell Multilane Packing Machine

Our packing machines are meticulously manufactured in China and supplied by well-known brands of components; Automatically pack stick sachets through multiple channels; Capable of producing large quantities of finished products to satisfy market demands. To preserve the integrity of liquid, granule, and powder products, our stick pack machine and multi-lane sachet pack machine can effectively fill and seal them in airtight containers/packaging.

The Makwell multi-lane packing machine may be integrated into an existing assembly line with other filling and labeling equipment, forming a complete manufacturing system. Choose a multi-lane sachet pack machine for sauces and liquids; a spiral stick pack machine for dry solid products like powder and granules.

Multilane Packing Machine

Stick Pack Machine

Features an auger (screw) filling system that produces 240-320 stick packs per minute, Ideal for packing powder and granule products.

Multi-Lane Sachet Packing Machine

8-10 lanes for producing 320-400 stick sachets per minute, best for packing liquids products.

2 Products Found.

Multilane Packing Machine Advantages

Fast Production Icon Multilane Packing Machine
Fast Production

The ability to produce several pouches simultaneously over many lanes significantly increases output and efficiency.

Precise Dispensing Icon Multilane Packing Machine
Precise Dispensing

Guarantee the highest possible standards of quality and safety. Designed to dispense product with extreme precision.

All-Round Capability Icon Multilane Packing Machine
All-Round Capability

Adaptable to handle a wide variety of products, from liquids to powder to granules, making this machine a wise investment.

Compact Design Icon Multilane Packing Machine
Compact Design

Space-saving, multi-lane designs, multi-lane packing machines help maximize productivity while minimizing footprint.

Multilane Packing Machine Features

Some machines may have more or fewer of the following features;

  • Intelligent PLC with Human Machine Interface.
  • Photocell tracking capability with excellent accuracy.
  • Reduce unnecessary film waste with the help of a film-empty alert.
  • Fast and easy integration of support equipment.
  • Fast changeover without the need for any tools.
  • Stopping in an emergency, counting, and ready-pack production.
  • Long-lasting SS 316 stainless steel construction.
  • Filling capacities for powder, grains, or liquids.
multilane pack machine
multilane packaging machine

Multilane Packaging Machine Technical Specifications

Among them are:

  • A maximum allowable machine weight of 900 kg.
  • Maximum 320 mm film roll diameter and 520 mm film width.
  • Power requirements are 220 V at either 50 Hz or 60 Hz.
  • 0.8 Mpa air pressure at 0.8 m3/min.
  • The range of lanes is between 1 and 12.
  • Stick bag ,3/4 sealing or back sealing capabilities.

Boost Your Business with Multilane Packing Machines

🔵 High-Quality Packaging
With the help of this machine, you may create attractive and high-quality stick packs.
🔵 Safety & Protection
The sensors will reduce potential for damage and waste in packing.
🔵 Hygiene
Versions that run automatically to maintain a high standard of cleanliness. Safely handle each step of the packing process.
🔵 Maximize Output
Boost productivity with adjustable stick packing speeds.
🔵 Reduce Ongoing Expenses
The cost of buying the automatic models could be high. Whereas will help save money over time on ongoing expenses.

multilane pack machine

Best Filler for Your Product

Powder Filler Auger Dosing Multilane Packing Machine
multilane pack machine
What is a stick pack machine?

Stick pack machines, like vertical form fill seal packaging machines, cut and shape a roll of film into several stick packs filled and sealed vertically.

What is a multilane packing machine?

A multi-lane packing machine uses multiple lanes to pack products into pouches and bags. Being able to run on several lanes allows this machine to pack many items at once.

What is a multilane stick pack packaging machine?

An excellent choice for packaging in bulk, this machine is modular and versatile, making it an automated vertical form fill seal machine. The key characteristics of this machine are its simplicity, reliability, and ease of operation and maintenance.

Featured packaging solutions for multilane pack machines are available for products that fall into the liquid, powder, or granular categories.





Liquid Filler (Piston Pump)

When using a plunger pump, you may store as much as 80000cps of product. Standard non-drip nozzles ensure that the sealing area is not contaminated.

Filling and packing is an option for many items, such as those listed here: peanut butter, ketchup, olive oil, mayonnaise, water, peanut butter, dairy products, processed cheese, antibacterial hand sanitizer, etc.

The CIP (clean in place) system and the double-jacketed tank heater are popular add-ons in addition to this filling equipment.





Powder Filler (Auger Dosing)

In the hopper, we often place additional agitators just in case. Having additional agitators in the hopper might come in handy if the composition of the powder product changes. A dust collector or some other method of dust extraction is needed in addition to the auger filling machine.

An automatic product feeder is also necessary alongside these auxiliary functions. An automatic feeder to maintain a constant product level is essential for auger fillers to operate well. A few examples of these products are protein powder, protein milk, medical powder, hiking powder, and protein powder.





Granule Filler (Volumetric System)

For granular goods, we provide a rotational, fully enclosed filler. When the shaft of the volumetric cups is in motion, granules are ground.

Unlike its linear counterparts, rotary granule feeders are able to maintain the surrounding area as clean as possible while still delivering the ground product to the filling funnel. Granules are used for a wide variety of items, and some common ones include sugar, yeast, salt, and medicine.

Multilane Packing Machine
Multilane Packing Machine Parts

A multilane packaging machine houses several moving parts. All of these components cooperate to make superior stick or sachet packs. Stick packs come in various types, but all serve the same purpose. As a result, certain parts may be present in one machine but absent in another.

🔵 Control Panel

This enables the user to control and see the packing process. It has an HMI and a PLC for controlling the machine’s functions. For convenience, the screen has buttons and visual aids. Any problems with the device will show on the interface.

🔵 Printer

Some machines don’t have these parts. It is optional, as certain film stocks contain prints. Printing information on the film strip that will wrap the items works. It can print the brand name, manufacturing date, and expiry date.

🔵 Roll Stock

The film holder is a circular part of the machine. During the packing procedure, the film unravels and becomes the packaging material for the items.

🔵 Sensor

This part helps avoid damage and injuries. It guarantees the consistency and efficacy of the multilane packing machine. When the sensor detects a problem, it will trigger an alarm to alert the user. The packaging machine might shut off if it detects danger. Problematic seals are identified and prevented from moving on—no leaks or spills with no pack or filling feature.

🔵 Blade Cutter

A long, hollow tube will result from the tube-forming process. The blades of the cutters cut the tubes into narrow strips. The filling material and dimensions will determine the length of the strip.

🔵 Hopper

The hopper holds all stick-pack goods initially. The hopper size might vary from machine to machine. The stick packaging process may go continuously as long as the materials are there.

🔵 Form Tube

As it enters the stick packaging machine, the sealing material stays flat. The hollow is created in the film material in the form tube. The products will be stored in the tube before sealing.

🔵 Sealing System

To avoid leaks and contamination, the machine will apply a seal once filling the items within the stick packs. Several sealing methods apply depending on the stick packaging machine’s design.

🔵 Dancer’s Arms

These have a set of rollers that aid in keeping the film tensioned. It also keeps the film from going off the rails.

🔵 Motor

This component will transform electrical energy into mechanical energy to power the machine’s workings.

🔵 Conveyor System

This facilitates the movement of materials within the device.

🔵 Electrical Unit

It houses all the necessary electrical components to power the stick packaging machine—electrical parts, including wires, fuses, etc.

🔵 Supporting Platform

This is the structural base of the multilane packing machine.


What is the purpose of a packaging machine?

We use a packing machine to pack products to get ready for distribution. It comprises automated form, fill, seal, wrap, clean, and package equipment. Packaging machines also include equipment that sorts, counts, and accumulates.

What are the different types of packaging machines?

Banding and strapping machines. Check and multi-head weighers. Wrapping machines: flow wrap, stretch, shrink. Fill and seal bags and pouches.

What is the use of a sachet filling machine?

A sachet packing machine packs granular and powder ingredients into small bags or sachets. This machine is excellent for food, pharmaceuticals, cleaning products, chemicals, etc. With the multi lane sachet packing machine, your efficiency will skyrocket.

multilane pack machine
Multilane Packing Machine Working Principle

How do automatic packing machine work?

Filling and Sealing

This machine can also load premade pouches and make bags from a roll of flat packaging material. The bags are opened, filled, and sealed when fed into the machine.

The multilane packing machine works on the same premise as vertical form fill seal packing machines. In specific stick packing machines, numerous lanes fulfill the same task. This makes the device fast-producing. Here’s how the machine works;

🔵 Film Transport and Unwinding

Check the machine’s condition before beginning any procedure. It starts the packaging process by relaying and unwinding the film. A single film sheet wraps the machine’s rolling stock while it operates. A film reel with cross-sealed jaws will grip the film as it unwinds and keeps moving. The cross-seal jaw is at the front of the packing machine, while the film reel is in the rear. The films may include content from:

  • Aluminum and Polyethylene [PE]
  • Nylon and Polyethylene [PE]
  • Paper and Polyethylene [PE]
  • Oriented polypropylene [OPP] and Polyethylene [PE]
🔵 Printing

Optional machine component. The operator feeds the film around the registration roller for date stamping machines. It will help place the pack date stamp. Sensors will recognize eye markings and adjust seal position during printing. Printers may include an ink-jet printer, a simple ribbon printer, and a thermal transfer printer.

🔵 Film Tension

The film is fed over nip rollers at this step. Nip rollers maintain a consistent tension in the film by applying a constant force throughout its surface. Keeping the dancer’s arm in the proper working posture is another benefit. In the back of the machine is a weighted pivot arm called the dancer’s arm. This dancer’s arm has many rollers. While maintaining tension, the arm will move up and down as the film unwinds. The film won’t be able to shift side to side now.

🔵 Film Cutting

After passing through the nip rollers, the film will go to the cutting area. The machine will then split the film into individual strips. The strip-cutting capacity is proportional to the number of available cutting lanes. The products’ packaging will be these strip packs. Furthermore, the blades are not powered by an electric motor. The film continues through the blades with the same tense energy it had at the beginning—special rollers help cut by coming into touch with these blades.

🔵 Stick Pack Making

The slit film will then be fed into a series of tubes. One strip may only cross one lane at a time. The collar of this component is where the slit film becomes a tube. The strip film will be folded within the tube so the ends overlap. The operator may also adjust the forming tubes to make either fin or lap seals.

To make a flat seal, lap seals overlap the two outside borders. Seals that resemble fins are from joining the inner and outer edges together. The lap seal is more aesthetically beautiful and uses less film than fin seals, making it the more practical choice.

🔵 Filling and Sealing

Hot vertical seal bars approach the film tube at this step. The film material will seal vertically when heated. One horizontal sealing jaw will then touch. This seals one stick pack top and the next bottom.

The bottom stick pack will then fall to the center of the forming tubes when the sealing jaws shut. After that, the product materials go into the stick pack tube. Ensure the proper quantity goes into the bags using auger filler, volumetric filler, or liquid pump filler.

🔵 Final Product Discharge

Once the stick packs are full, blades move in to cut them. Also, a notch may develop behind a horizontal seal’s jaw. The slashed stick packs will fall down the infeed chutes. These chutes contain flaps that open and shut at predetermined intervals.

The packets then go to the outfeed conveyor system or the containers after exiting the outfeed chutes. Single outfeed chutes assist in regulating and positioning stick or sachet packs.

What is the use of a sachet filling machine?

Disposable and sachet-based packaging solutions, including ampules, capsules, pills, and vials, find extensive use in liquid sachet filling machines, and other sachet packing machines. A growing number of food and beverage products are being packaged in sachets.

Multilane Packing Machine Selection

Multi-Lane Liquid Packing Machine
Multi-Lane Liquid Packing Machine

This device is used for measuring and packaging liquids like sauces and condiments in industries including food, medicine, and cosmetics.

Multilane Powder Packing Machine
Multilane Powder Packing Machine

Provides a multi-lane stick packing machine with 4-12 lanes for powders.

Multilane Granule Packing Machine
Multilane Granule Packing Machine

Multilane granule stick pack machine with 4-12 lanes for sugar, salt, ground coffee, spice, and other items.

Multilane Liquid Four Side Sealing Sachet Machine
Multilane Liquid Four Side Sealing Sachet Machine

Uses for this machine include measuring and packaging liquids like sauces and condiments for the culinary, pharmaceutical, chemical, and personal care industries.

Multilane Powder Four Side Sealing Sachet Machine
Multilane Powder Four Side Sealing Sachet Machine

Powder multilane packaging machine has two to ten lanes, for four-side sealed sachets.

Multi-Lane Granule Four Side Sealing Sachet Machine
Multi-Lane Granule Four Side Sealing Sachet Machine

Granule four-sided sealing sachet machine with many lanes for salt, sugar, coffee seasoning, etc.

MAKWELL - The Best Packaging Machine Supplier in China

Makwell Multilane Packing Machine

What are the Applications and Benefits of a Multilane Packing Machine?

In the manufacturing lines, many different types of businesses make use of multilane packaging machines. These sectors include the industries:

🔵 Pharmaceuticals

The pharmaceutical products that patients use will be packaged by these businesses. They come in convenient single-serving packets with just the appropriate amount of medication.

🔵 Cosmetics

They’re responsible for the attractive packaging of cosmetics and toiletries. Body oils, lotions, colors, etc., fall within this category.

🔵 Food

Several sectors of the food industry rely on this device to provide a marketable, inexpensive, and user-friendly final result. Sugar, glucose, candy, coffee, and so on are all good examples.

🔵 Chemicals

This industry makes use of this equipment for a variety of packing tasks, including acid and reactive chemical packaging.

Multilane Packaging Machine Benefits

Utilizing a multilane packing machine comes with a number of distinct benefits, some of which are as follows:

🔵 Precision

Stick packing machines are known for their high levels of accuracy and reliability, as well as their ability to save time and reach large production volumes.

🔵 High-Tech Sensors

Throughout the stick packing process, automatic sensors will protect against any damages, risks, or losses that may occur.

🔵 Effortless Use

These packaging machines, whether fully or semi-automatic, are simple to use. This indicates that the equipment can be used with a minimal amount of instruction.

🔵 Time-Saver

A stick packing machine is capable of producing many stick packs in a relatively short amount of time. Because of this, you will be able to fulfill all of your manufacturing requirements as they arise.

🔵 Adaptable

Multilane packaging machines are versatile enough to accommodate a variety of auxiliary pieces of packing equipment. Some examples of this kind of packing include cases and cartons.

🔵 Production Capacity

There is a range of manufacturing speeds available for these packaging machines. Because of this, you can modify the pace of production in accordance with your requirements.

🔵 Simple Maintenance

A stick packaging machine requires very little in the way of upkeep and maintenance. This makes it simple for the operator to repair or replace any necessary sections.

🔵 Economical

This machine satisfies your production requirements while reducing your overall operating expenses. If you were previously engaging in manual stick packing, this would result in a reduction in the amount of money you must pay your operators.

How Does a Multilane Compare to a Single Lane Stick Packing Machine?

The single-lane stick packaging machine makes vertical stick packs. Multilane stick packing machines make stick packs in various vertical designs.

Multi-lane packing machines produce more than single-lane machines. Single-lane machines work well for small to medium-sized stick packaging industries. Whereas, major businesses best use multiple-lane stick packaging machines.

What are the stick packing machine sealing options available?

There are a few different ways the machine can seal packaging. They are:

  1. Ultrasonic
  2. Heat seal
  3. Induction
What Influences the Stick Packing Machine Cost?

Many things come into play, including:

  • Automation complexity
  • Machine component brands, designs, features, and model types.
  • Your origin location
  • Speed of production
  • Economy and market, supply and demand
  • Sales and discount offerings
